Ports
● 48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
● 2 dual-personality ports; auto-sensing 10/100/1000BASE-T or SFP
● 2 fixed 1000/10000 SFP+ ports
● 1 RJ-45 serial console port
● 1 RJ-45 out-of-band management port
● 1 extended module slot
Memory
● 1 GB SDRAM
● 64 MB flash
● packet buffer size: 1 GB
Performance
● Throughput: 119 million pps (64-byte packets)
● Switching capacity: 160 Gbps
● Routing table size: 12000 entrie
● MAC address table size: 32000 entries
Additional specifications
● Static MAC table: 5120
● Max VLAN interface: 1K
● Multicast L2 entries for IPv4: 2K
● Multicast L2 entries for IPv6: 1K
● Multicast L3 entries for IPv4: 2K
● Multicast L3 entries for IPv6: 1K
● VLAN table: 4K
● QOS forward queue number: 8
● Static ARP number: 1K
● Dynamic ARP number: 8K
● MAX number in one link group: 8
● Link group number: 128
● ACL number: 4K (ingress); 512 (egress)
Power supplies
● 2 power supply slots
● 1 minimum power supply required (ordered separately)
Fan tray
● 1 fan tray slot
Physical characteristics
● 1U
● 46 x 44 x 4.36 cm
● 6.59 kg
| Общие | |
|---|---|
| Размещение | Монтируемые в стойку |
| Тип коммутатора | |
| Тип коммутатора | Управляемый L3 |
| Интерфейсы | |
| Тип основных портов | GigabitEthernet RJ45 |
| Интерфейсы 10/100/1000BaseT | 48 |
| Из них комбо 10/100/1000BaseT | 1000BaseX SFP | 2 |
| Интерфейсы 10GBase-X SFP+ | 2 |
| Тип Uplink портов | 10GigabitEthernet SFP+ |
| L2 функционал | |
| Количество VLAN | 1000 |
| Размер таблицы MAC адресов | 5120 |
| L3 функционал | |
| Размер таблицы ARP | 1000 |
